Pressure distillation range tester FDR-0301

TechnicalSpecifications

The instrumentis designed and made as per the Industry Standard of Peoples Republic of ChinaSH/T0165-92 Test Method for Distillation of High Boiling Point PetroleumProducts under Vacuum Condition. It is used for distillation of waxy oil,lubricating oils and similar high boiling point petroleum products. .Is ahigh-viscosity petroleum products for determination of distillation range ofspecial equipment. For determination of high wax and oil boiling rangepetroleum products - Determination of distillation under reduced pressuredistillation range of sample approach. instrument consists of distillationflask furnace, Heating power regulator, receptorGraduated flask receiver andair bath Temperature control system, vacuum system, vacuum gauge, lightingsystems and or components.

FunctionFeatures

1,pressuredistillation range tester with integrated design, easy operation and maintenance
2,pressure distillation range tester system with PID Temperature control Temperaturecontrol, Temperature control, high precision, stable
{1}3,{/1} high-vacuum chamberGraduated flask vacuum distillation analyzer usingair bath, digital Temperature control
4,pressure distillation range tester using low-noise vacuum system
5,pressure distillation range tester using mercury manometer display, easy toread

TechnicalSpecification

1, Input power: <2050 W

2, distilled adjustable heating power:0-1200W

3, receiving cylinder Temperature controlrange: room Temperature to 90 degrees

4, Temperature Power: 800W

5, the buffer tank volume: 1200ml

6, Power supply: 220V 50HZ

7, maximum residual pressure pump: ≤ 2mm Hg
